Maxsure Tec
Features
4*330W solar panels
4*150Ah/6*150Ah/8*200Ah gel batteries (optional) DC24V system
4*60W/4*100W/6*100W LED light (optional)
Optional 6 to 9 meters manual/electric/hydraulic mast
Dual axle trailer
TECH SPECS: | ||||||||||||||||||||
TOWER | DIMENSIONS | LIGHTING FIXTURE DETAILS | ||||||||||||||||||
Length: | A470mm | Type of Lights: | LED | |||||||||||||||||
Width: | 2030mm | Lamp Wattage: 60/100W | ||||||||||||||||||
Height: | 2750mm | No.of lights: | 4/6 | |||||||||||||||||
Weight: | 1850kg | Light Output(W): 2401400/600 | ||||||||||||||||||
TRAILER DETAILS | Lumens per Watt: 150 | |||||||||||||||||||
Trailer Type: Dual Axle | Working Life Time(hr):50000 | |||||||||||||||||||
Tire and Rim Size: 15" | Light Bar Rotation: 355 Degrees | |||||||||||||||||||
Stabalizer Supports:4xManual | Light Bar Tilt: Optional | |||||||||||||||||||
Drawbar: A Frame | Mast Raise/Extension: Manual/Electric/Hydraulic | |||||||||||||||||||
Tow Hitch: 50mm Ball/70mm Ring | Mast Height(m): Optional | |||||||||||||||||||
Mud Guard/Wheel Chock: | Special Design | Coil Cable: 4*4sqmm/4*6sqmm | ||||||||||||||||||
Backup Generator: Optional | Wind Rating Speed: 100km/h | |||||||||||||||||||
Working Temperature(℃): | -35~60 | |||||||||||||||||||
SELECTION TABLE: | ||||||||||||||||||||
Code Solar Panel(W) LED(W) Mast(m) Battery(Ah) Generator(kW) Trailer Standard | ||||||||||||||||||||
VTS1200B-L | 4*330W (fixed angle) | 240(4*60W) 400(4*100W) 600(6*100W) | MM (manual mast) | 6 | B900(6*150Ah) B1200(8*150Ah’ B1600(8*200Ah) | G3(gasoline 3kW) D3(diesel 3kW) D5(diesel 5kW) | AU/ US/ EU | EB(eletric brake) MB(mechanical brake) | ||||||||||||
7.5 | ||||||||||||||||||||
9 | ||||||||||||||||||||
EM (electric mast) | 6 | |||||||||||||||||||
7.5 | ||||||||||||||||||||
9 | ||||||||||||||||||||
HM (hydraulic mast) | 6 | |||||||||||||||||||
7.5 | ||||||||||||||||||||
Application Scenario
Outdoor Engineering Projects: The Energy Saving Solar Lighting Tower is an ideal lighting solution for various outdoor engineering projects. It can be used to illuminate construction sites, roadworks, bridges, tunnels, and other infrastructure projects. With its portability and easy setup, it offers flexibility in positioning and adjusting the lighting according to the project's requirements. The solar-powered feature eliminates the need for additional power sources, reducing operational costs and environmental impact.
