Maxsure Tec
Features
8*330W solar panels
12*150Ah/16*150Ah gel batteries (optional) DC24V/DC48V system
4*60W/4*100W/6*100W LED light (optional)
Optional 6 to 9 meters manual/electric/hydraulic mast
Dual axle trailer
| TECH SPECS: | ||||||||||||||||||
| TOWER | DIMENSIONS | |||||||||||||||||
| LIGHTING FIXTURE DETAILS | ||||||||||||||||||
| Length: | 4700mm | |||||||||||||||||
| Type of Lights: | LED | |||||||||||||||||
| Width: | 2150mm | |||||||||||||||||
| Lamp Wattage: | 60/100W | |||||||||||||||||
| Height: | 2750mm | |||||||||||||||||
| No.of lights: | 4/6 | |||||||||||||||||
| 2460kg | ||||||||||||||||||
| Weight: | Light Output(W) | 2401400/600 | ||||||||||||||||
| TRAILER DETAILS | ||||||||||||||||||
| Lumens per Watt: | 150 | |||||||||||||||||
| Trailer Type: Dual Axle | ||||||||||||||||||
| Working Life Time(hr): | 50000 | |||||||||||||||||
| Tire and Rim Size: 15" | ||||||||||||||||||
| Light Bar Rotation: | 355 Degrees | |||||||||||||||||
| Stabalizer Supports: 4xManual | ||||||||||||||||||
| Light Bar Tilt: | Optional | |||||||||||||||||
| Drawbar: A Frame | ||||||||||||||||||
| Mast Raise/Extension: Manual/Electric/Hydraulic | ||||||||||||||||||
| Tow Hitch: 50mm Ball/70mm Ring | ||||||||||||||||||
| Mast Height(m): | Optional | |||||||||||||||||
| Mud Guard/Wheel Chock: | Special Design | |||||||||||||||||
| Coil Cable: | 4*4sqmm/4*6sqmm | |||||||||||||||||
| Working Temperature(℃): | -35~60 | |||||||||||||||||
| Wind Rating Speed: | 100km/h | |||||||||||||||||
| SELECTION TABLE: | ||||||||||||||||||
| Code Solar Panel(W) LED(W) Mast(m) Battery(Ah) Trailer Standard | ||||||||||||||||||
| VTS2400A-L | 8*330W (adjustable angle) | 240(4*60W) 400(4*100W) 600(6*100W) | MM (manual mast) | 6 | B1800(12*150Ah) B2400(16*150Ah) | AU/US/EU | EB(eletric brake) MB(mechanical brake) | |||||||||||
| 7.5 | ||||||||||||||||||
| 9 | ||||||||||||||||||
| EM (electric mast) | 6 | |||||||||||||||||
| 7.5 | ||||||||||||||||||
| 9 | ||||||||||||||||||
| HM (hydraulic mast) | 6 | |||||||||||||||||
| 7.5 | ||||||||||||||||||
| 9 | ||||||||||||||||||
Application Scenario
Outdoor Construction Sites: This Lighting Tower with High Power Solar Panels is perfectly suited for outdoor construction sites where reliable and efficient lighting is essential. With its high-power solar panels, it can provide bright illumination for workers to carry out their tasks even during nighttime or low-light conditions. The tower's robust design ensures durability and stability, making it suitable for various construction projects such as roadworks, building construction, and infrastructure development.
Mining Areas: In mining areas, where conventional power sources may be limited or unavailable, this Lighting Tower proves to be an ideal lighting solution. Its high-power solar panels harness the abundant sunlight, converting it into electricity to power the tower's lights. This ensures a safe and well-illuminated environment for miners to work efficiently and effectively, reducing the risk of accidents and improving overall productivity.
Ports and Docks: Ports and docks often require lighting solutions that can withstand harsh weather conditions and provide reliable illumination for various operations. This Lighting Tower excels in such scenarios, offering high-power lighting to facilitate loading and unloading activities, enhance safety during vessel maneuvering, and improve overall visibility in the port area. The tower's solar panels ensure uninterrupted lighting, even in remote or off-grid locations, reducing the reliance on traditional power sources.
Outdoor traffic safety equipment and outdoor engineering equipment products are important equipment to ensure people's safety during outdoor activities. These devices can not only improve people's safety in outdoor activities, but also improve the efficiency and quality of engineering construction. The following are our technical and service advantages.
Technical advantages:
1. Modern outdoor traffic safety equipment and engineering equipment adopt high-precision positioning technology, which can accurately locate the positions of personnel and equipment, improve safety and work efficiency.
2. These devices are equipped with intelligent monitoring systems, which can monitor the operating status and working environment of the devices in real time, detect problems in a timely manner, and take measures to ensure safety and stability.
3. These devices are made of high-strength materials, which have good wear resistance and corrosion resistance, and can be used for a long time in harsh outdoor environments.
4. These devices adopt high-efficiency and energy-saving technology, which can reduce energy consumption and operating costs, improve the service life and economic benefits of the equipment.
Service advantages:
1. providing customized services, designing and producing products that meet customer needs and requirements.
2. providing comprehensive after-sales service, including installation and debugging, training services, maintenance, etc., to ensure that customers can use the equipment normally and maintain its good condition.
3. Providing technical support, including equipment operation guidance, troubleshooting, maintenance and other services, to help customers solve problems during equipment use.
4. providing quickly respond to customer needs, promptly address customer issues and feedback, and ensure that customers can obtain a satisfactory service experience.
Our products have advanced technological advantages and high-quality service advantages, which can provide safe and efficient guarantees for outdoor activities and engineering construction. With the continuous development and progress of technology, these devices will continuously improve their performance and service level, bringing more convenience and safety assurance to people's outdoor life and engineering construction.
