Maxsure Tec
Features
Clean,quiet and efficient Kipordieselgeneratorset.(Other poweroptions are available on request)
Optimised cylinder head configuration foroptimum fuel and oil consumption andmaximum efficiency
Cyclone style air cleaner and earth leakageprotection
Residual Current Device(RCD)protection,and RCDmain switch installed in generatorsupply circuit with a test point
Circuit breaker installed into lighting circuitand all circuit breakers are fitted in IP56 enclosures
Tower Details | |||||||||
Environmental: | Bunded | Total Lumens: | 176000 | ||||||
Light Output in KW: | 1600W | Lumens per Watt | 110.0 | ||||||
Mast Height m/ft: | 9m/29'6' | Fuel Capacity | 15L |
Tower dimensions | |
Width: 1000mm/3'3" | |
Length: 1900mm/6'2" | |
Height: 2500mm/8'2" | |
Wetweight: 450 |
Equipment details | |||
Fuel: Diesel | |||
Genset: Kipor5Kw | |||
No.Engine Cylinders: 3 | |||
Engine: Nature Aspiration Alternator: MeccalteLT3M-130/4 | |||
Hz: 50/60 Tire and Rim size: 13" Stabaliser Supports: Jacks | |||
Tow Hitch: 50mm |
Light details | |||
Type of Lights: | MH | ||
Lamp Wattage: | 400W | ||
No.of lights: | 4 | ||
Light Output in KW Light Tilt: Mast Raise/ Extension: | 1600W N/A Manual | ||
Mast Height m/ft: Mast Rotation: Wind Rating | 9/29'6" 359° | ||
Speed: | 100 km/h |
